PSV, deck area 720 m2, DP2, built in 2008 in Europe

Vessel Specifications

• Type: DP 2 Platform Supply Vessel, 6,690 BHP
• Construction/Year: 2008
• Classification: ABS, A1, FFV1, AMS, ACCU, DPS-2, DK(+), HL(2.5), LFL(*), SF
• LOA: 73.4 m
• Breadth (Moulded): 16.6 m
• Depth (Moulded): 7.6 m
• Draft: Max - 6.4 m
• GRT: 2,661 t
• NRT: 902 t
• Deadweight: 3,486 mt
• Main Engines: 2 x 3,345 BHP
• Bow Thrusters: 2 x 790 BHP
• Stern Thrusters: 2 x 790 BHP
• Propellers: 2 x CPP
• Capstans: 2 x 8 t
• Deck Crane: 1 x 3 t @ 15 m
• Tugger Winch: 2 x 10 t
• Speed & Consumption: Idling / Standby: Abt. 2 m³, @ DP / day: Abt. 8.5 m³, @ 10 Knots / day: Abt. 8 m³, @ 13.5 Knots / day: Abt. 12 m³, @ 15 Knots / day: Abt. 25 m³
• Deck Area: 720 m² (52.2 m x 13.8 m)
• Deck Load: 1,600 t
• Deck Strength: 5 t/m²
• Fuel Oil: 1,042 m³
• Potable Water: 773 m³
• Drill Water / Ballast: 706 m³
• Oil Based Mud: 6,742 bbls @ 100% multipurpose tanks
• Base Oil: 6,742 bbls @ 100% multipurpose tanks
• Brine: 6,742 bbls @ 100% multi purpose tanks
• Dry Bulk: 12,016 ft³ @ 100%
• Methanol: 191 m³
• Discharge Rates - Fuel: 2 x 100 m³/hr
• Discharge Rates - Potable Water: 2 x 100 m³/hr
• Discharge Rates - Oil Based Mud: 2 x 100 m³/hr
• Discharge Rates - Brine: 2 x 70 m³/hr
• Discharge Rates - Drill Water: 2 x 100 m³/hr
• Discharge Rates - Base Oil: 1 x 90 m³/hr
• Discharge Rates - Dry Bulk: 2 x 75 m³/hr
• Discharge Rates - Methanol: 2 x 75 m³/hr
• Accommodation: 6 x 1-man, 6 x 2-man, 4 x 4-man, 1 x Hospital
• GMDSS: A3
