New Built MPSV, LOA 85 m, DP2, Accomm 200 prs, Helideck

Vessel Specifications

• Type: NB MPSV
• Location: For sale in China
• LOA: 85 m
• Beam: 22 m
• Draft: 6.2 m
• Moon Pool: 8 x 8 m
• Heli-deck: Sikorsky S61 type
• Class Notation: ABS ✠A1 Ⓔ Offshore Support Vessel (Supply-CHEM, FFV1), SPS, ACCU, RW, CRC, +AMS, +DPS-2
• Main Engines: 2 x 3,000 BHP, Niigata
• Propulsion: 2 x azimuth thrusters
• Deck Area: 700 m², 800 t at 7.5 t/m²
• Deck Cargo: 800 t
• Deck Loading: 7.5 t/m²
• Fuel Oil: ~1,150 m³
• Fresh Water: ~740 m³
• Drill Water/Water Ballast: ~1,750 m³
• Heeling: ~450 m³
• Cargo Delivery:
• Fuel Oil: 2 x 150 m³/hr @ 75 m head
• Fresh Water: 1 x 150 m³/hr @ 75 m head
• Drill Water: 1 x 150 m³/hr @ 75 m head
• GS/Fire: 1 x 100 m³/hr @ 75 m head
• Sludge: 1 x 5 m³/hr @ 29 m head
• Ballast: 1 x 200 m³/hr @ 40 m head
• Accommodation: Total 200 persons (6 x 1-man cabin, 15 x 2-men cabin, 41 x 4-men cabin, 1 x hospital for 2 persons)
• Chiller: ~24 m³ (approx)
• Freezer: ~24 m³ (approx)
• Amenities: Cinema, Client Day Room, Conference Rooms, Fitness Room
• Main Crane: AHC 100 t at 15 m
• Deck Crane: 1 x marine crane, 5 t SWL @ 14.0 m
• Tugger Winch: 2 x electro-hydraulic type, 10 t @ 15 m/min
• Delivery: Mid 2026 in China
